Automatic 3-in-1 Juice Filling Machine for PET Bottles
An Automatic 3-in-1 Plastic Bottle Juice Filling Machine integrates rinsing, hot filling, and capping in one compact unit. It is designed for high-speed bottling of juices, teas, and non-carbonated beverages into PET bottles. The system ensures sanitary filling, precise volume control, and stable cap application, making it ideal for medium to large juice production lines.
Specifications
| Model: | CGF12/12/6 | CGF18/18/6 | CGF24/24/6 | CGF32/32/12 | CGF40/40/12 | CGF48/48/12 |
| Production Capacity: 500ml(B/h) | 4000 | 6000 | 10000 | 14000 | 17000 | 20000 |
| Suitable Bottle Standard: (mm) | 150-300 | 150-340 | 150-340 | 150-340 | 150-340 | 150-340 |
| Suitable Cap Standard: (mm) | φ 50-φ 110 | |||||
| Filling Pressure: (Mpa) | 0.2-0.3 | |||||
| Installed Capacity: (L) | 3.13 | 3.84 | 3.84 | 5.6 | 6.3 | 7.3 |
| Filling Temperature: | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature | Room Temperature |
| Overall Size: L× W× H(mm) | 2400× 1670 × 2350 | 2470× 1970 × 2350 | 2865× 2170 × 2350 | 3700× 2570 × 2350 | 3800× 2950 × 2400 | 4500× 3400 × 2400 |
| Total Weight: (kg) | 2500 | 3000 | 4000 | 5000 | 6000 | 7000 |
Video
Description
Rinsing Unit
-
Rotary rinsing system equipped with stainless steel grippers and spring-loaded nozzles.
-
Bottles are inverted 180° for inside-out cleaning using sterile water or ionized air.
-
No-bottle, no-rinse design ensures zero waste.
Filling Unit
-
Hot filling valves with constant-temperature control (85–90°C) to preserve juice quality.
-
Flow meter or gravity-based filling options available.
-
CIP (Clean-in-Place) system with automatic tank sterilization.
Capping Unit
-
Magnetic torque capping head ensures consistent sealing torque, protecting cap integrity.
-
Cap sorter and chute designed for flat or sports caps.
-
No-bottle, no-cap feeding system to prevent waste and machine damage.
